THERMO dc solar pump is a brushless DC motor design with dry-running protection, over-current protection, blocked protection, over-voltage protection, under-voltage protection, reverse protection, constant power and over-temperature protection. Its a Solar DC Circulation Water Pump that used for hot water heater circulation, solar water heater, heating system, solar power system etc.
Max Flow :
11L/min, 14L/minMax Head :
3M, 5.5MRated Power :
10W, 20WCustomized :
Acceptable12 Volt DC Solar Water Pump Supplier
A smart water circulation pump for solar water heater is an advanced device that helps improve the efficiency and convenience of the solar water heating system. It is designed to circulate the hot water from the solar collector to the storage tank or directly to the desired point of use, such as showers or faucets.
This model of Solar DC Circulation Pump is widely used in solar whole house hot water system, solar water heater, hot water circulation, floor heating, cooling system and other fields. THERMO Solar hot water circulating pump CWP020G/WC12 is designed with 220V input voltage and 12V DC working voltage, rated flow 9~14L/MIN, rated head 2.3~5.5M, rated power 10W/20W, low noise at 1M ≤40dB and long lifetime more than 20,000H, but its compact and small size only with weight 650g.
The feature of THERMO dc solar pump are:
l Compact and small size with light weight 650g
l Long lifetime ≥20,000H
l Lower noise ≤40dB@1m
l Dry-running protection
l Over-current protection
l Blocked protection
l Over-voltage protection
l Lower-voltage protection
l Over-temperature protection
l Constant power
l Reverse protection
l PWM Control & FG Signal Customization
l Liquid temperature range from -15~100℃, Ambient temperature range from -25~55℃
l Static seal design to prevent leakage
Thermo Pumps win a good reputation in the market after several years. Its with widely applications including: bidet toilet, water heated blanket, water heater, gas boiler electric vehicle, liquid cooled ultra-fast charging, computer cooling, motorcycle, aquarium, ice maker, water dispenser, coffee machine, beverage machine, dishwasher and others kitchen appliances.
